Modułowy przełącznik wieloformatowy Kramer VS-6464DN
8x8 to 64x64 Modular Multi–Format Digital Matrix Switcher
SKU
VS-6464DN
The VS−6464DN is a modular matrix switcher chassis for DVI & HDMI signals populated from 8x8 to 64x64 in increments of eight inputs and/or eight outputs. The product includes a power supply and control and test modules. The test module can monitor and test any input and output in the matrix.
- Kramer Core™ — FLEXIBLE INFRASTRUCTURE CONVERSION! Copper, Fiber or Twisted Pair — all can be used at the same time, according to input/output module selection. The matrix receives digital signals from compatible Kramer transmitters, automatically converts between available infrastructure options and sends the signals to compatible Kramer receivers. Kramer Core™ solution is the ultimate in versatility!
- Max. Data Rate — 10.2Gbps (3.4Gbps per graphic channel) depending on the cards used.
- HDTV Compatible.
- HDCP Compliant — With DVI (HDCP) & HDMI.
- Kramer Equalization & re‑Klocking™ Technology — Rebuilds the digital signal to travel longer distances.
- Modular & Easily Configurable Platform — Input or output module types can be mixed and added in increments of 8 from 8x8 up to 64x64.
- Available Modules — DVI, DVI (HDCP), DVI over Fiber.
- EDID Capture — Copies and stores the EDID from a display device.
- Flexible Control Options — Front panel, IR remote (included), RS–232 (K–Router™ Windows®–based software is included), Ethernet.
- Front Panel Lockout.
- Take Button — Executes multiple switches all at once.
- Memory Locations — Stores multiple switches as presets to be recalled and executed as needed.
- Built–in Test Pattern Module — With 4 output resolutions for troubleshooting video problems.
- Additional Monitoring Port.
- Optional Redundant Power Supply — PS–1DN, hot–swappable.
- Worldwide Power Supply — 100–240V AC.
- Standard 19” Rack Mount Size — 10U. Rack “ears” included.
Standardy | DVI, HDCP, HDTV, HDMI |
---|---|
Sterowanie | Ethernet, RS-232, IR |
Seria | 19" 10U |
Skrót właściwości | 8x8 to 64x64 Modular Multi–Format Digital Matrix Switcher |
