Modułowy przełącznik wieloformatowy Kramer VS-3232DN

Modułowy przełącznik od 4x4 do 32x32 sygnałów DVI i HDMI.
SKU
VS-3232DN

VS−3232DN is a high−performance 4x4 to 32x32 modular matrix switcher chassis for AV signals. The unit is a multi−format digital switcher, populated from 4x4 to 32x32 in increments of four inputs and/or four outputs. The chassis includes optional dual, redundant power supplies, a control module and a test module that can monitor and test any input and output in the matrix. VS−3232DN supports a wide variety of input and output cards for different AV signals.

  • Kramer Core™ — FLEXIBLE INFRASTRUCTURE CONVERSION! Copper, Fiber or Twisted Pair — all can be used at the same time, according to input/output module selection. The matrix receives digital signals from compatible Kramer transmitters, automatically converts between available infrastructure options and sends the signals to compatible Kramer receivers. Kramer Core™ solution is the ultimate in versatility!
  • Max. Data Rate — 10.2Gbps (3.4Gbps per graphics channel) when using compatible cards.
  • HDTV Compatible.
  • HDCP Compliant — With DVI (HDCP), HDMI, F670, HDBaseT, DGKat modules.
  • HDMI Support
  • Cables — For optimum range and performance, use recommended Kramer cables.
  • Kramer Equalization & re‑Klocking™ Technology — Rebuilds the digital signal to travel longer distances.
  • Optional Fast Switching Support — For fraction of a second switching.
  • Modular & Easily Configurable Platform — Input or output module types can be mixed and added in increments of 4 from 4x4 up to 32x32.
  • Protocol 3000 Support.
  • Flexible Configuration — To disable HDCP support and convert between HDMI and DVI.
  • Default EDID — For each input.
  • EDID Capture — Copies and stores the EDID from a display device.
  • Take Button — Executes multiple switches all at once.
  • Memory Locations — Stores multiple switches as presets to be recalled and executed as needed.
  • Test Pattern Module — With 4 output resolutions for troubleshooting video problems and additional monitor port with audio embedding and de–embedding.
  • Front Panel Lockout.
  • Redundant Power Supply — Hot–swappable, 2 separate units with independent power inlets.
  • Flexible Control Options — Front panel, IR remote (included), RS–232 (K–Router™ Windows®–based software is included), Ethernet.
  • Worldwide Power Supply — 100–240V AC.
Specyfikacja techniczna
Standardy DVI, HDCP, HDTV, HDMI, HDBaseT, DGKat
Sterowanie Ethernet, RS-232, IR
Seria 19" 6U
Skrót właściwości Modułowy przełącznik od 4x4 do 32x32 sygnałów DVI i HDMI.
