Przełącznik ze skalerem Kramer VP-725N

Przełącznik 5:4x1 sygnałów HDMI, VGA, CV, s-Video i YUV. Wysyła przeskalowane sygnały na wyjściach HDMI, VGA i RGBHV.
SKU
VP-725N

The VP−725N is a presentation scaler/switcher with multiple signal format sections. The unit has five independent 4x1 video sections: composite, s−Video (Y/C), component (YUV), computer graphics, and HDMI, plus a single USB input. It also up− or down−scales any video input to a selectable graphics or HDTV output resolution. FTB™ (fade−thru−black) switching technology provides glitch−free switching between sources.

  • HQV® Video Processing — HQV (Hollywood Quality Video) processing represents the state–of–the–art in video processing technology, with the highest quality de–interlacing (with 3:2 & 2:2 pull down), noise reduction, and scaling performance for both standard–definition and high–definition signals.
  • Deinterlacing and Scaling — High–quality 3:2 and 2:2 pull down, de–interlacing and full up — and down–scaling of computer graphics video input signals.
  • HDTV Compatible.
  • HDCP Compliant — The HDCP (High Definition Content Protection) license agreement allows copy–protected data on the HDMI input to pass only to the HDMI output.
  • Fade–Thru–Black (FTB™) Switching (Scaled Output) — The video fades to black and then the new input fades from black for smooth, glitch–free switching. The output signal provides constant sync so the display never glitches.
  • K–IIT XL™ Picture–in–Picture Image Insertion Technology — Ultra stable picture–in–picture, picture–and–picture, and split screen capability. Any video source can be inserted into or positioned next to a computer graphics video source or vice versa with window positioning and sizing controls.
  • Projector Anywhere™ Technology — Horizontal & vertical geometry controls compensate for off–axis projector placement.
  • Multi–Format — Auto, NTSC (3.58/4.43), PAL (M/N/60) & SECAM.
  • 6 Switchers in 1 — Five dedicated signal formats: 4x1 composite, 4x1 s–Video (Y/C), 4x1 component (RGB/YUV), 4x1 computer graphics (15–pin HD), 4x1 HDMI and one 21x1:3 scaled output.
  • USB Port — For importing JPEG files.
  • Scaled Computer & HDTV Outputs — A single output signal in 3 formats (15–pin HD, 5 BNCs, and HDMI) simultaneously.
  • HDTV Compatible Component Input.
  • HDTV Output Resolutions — 720p, 1080i, and 1080p.
  • Computer Graphics Output Resolutions — 23 plus 4 user definable custom output resolutions with selectable refresh rates.
  • Multiple Color Space — RGB or YUV output.
  • Flexible Control — Front panel, IR remote (with on–screen menus), Ethernet & RS–232.
  • Standard 19” Rack Mount Size — 3U. Rack “ears” included.
Specyfikacja techniczna
Standardy UXGA, HDMI, RGBHV
Wejścia HDMI, VGA, Component, Composite CV, s-Video Y/C
Wyjścia HDMI, VGA, Composite CV, Component YUV, s-Video Y/C
Sterowanie Ethernet, RS-232, IR
Seria 19" 3U
Skrót właściwości Przełącznik 5:4x1 sygnałów HDMI, VGA, CV, s-Video i YUV. Wysyła przeskalowane sygnały na wyjściach HDMI, VGA i RGBHV.
